Technical specification

• Transmission channel
  3G / 2G / LAN
• Frequency band
  900/2100 MHz @UMTS, 900/1800 @GSM/GPRS
• Operating temperature
  -20 ºC - +70 ºC
• Supply voltage
  12-24 VDC
• Current consumption (maximum)
  700 mA @ 12 VDC
• Casing
  Plastic
• Dimensions
  130x69x19 mm
• Weight
  200 g

Inputs

• Contact inputs
  6
• Configurable inputs (NO/NC)
  Yes
• EOL inputs
  Yes
• Adjustable input sensitivity
  Yes

Outputs

• Relay outputs
  6

Notifications

• E-mail sending
  Yes
• Push Notification
  Yes
• VoIP voice call
  Yes
• VoIP SMS sending
  Yes
• IP-based reporting to CMS
  Yes

Supported protocols

• SIA IP DC-09 protocol
  Yes
• TELLMon protocol
  Yes
• TEX protocol
  Yes

Programming

• Programming method
  IP

Remote monitoring

• Monitoring station IP addresses
  6
• Individual reporting to monitoring station
  Yes

Other functions

• Configurable internal Contact ID event codes
  Yes
• Security password
  Yes
• Contact ID event code filtering
  Yes
• Event logs / number of stored events
  Yes / 1200
• Mobile application
  Yes
• Individual email sending with predefinable message
  Yes
• Individual SMS sending to user phone numbers with predefinable message
  Yes
• Periodic test report
  Yes
• Alarm sending to user phone numbers with siren tone being used
  Yes
• Alarm restriction
  Yes
• Recordable voice message sending to user phone numbers
  Yes
• Generates SMS from Contact ID event codes and sends to user phone numbers
  Yes
• Phone line emulation
  No
• NTP server support
  Yes
• RADIUS server support
  Yes
• Router supervision
  Yes
• Transparent serial port support
  Yes
• IP camera support
  Yes
• Connecting remote modules for output controlling
  Yes
