Camera

Image Sensor

1/1.8”4Megapixel progressive CMOS

Effective Pixels

2688 (H) ×1520 (V)

ROM

128 MB

RAM

512 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s

Min. Illumination

0.004 Lux@F2.0 (Color, 1/3 s, 30 IRE)

IR Distance

10 m (32.8 ft) (monitoring distance)

IR On/Off Control

Auto

IR LEDs Number

2

Pan/Tilt/Rotation Range

Vertical: -10° to +10°
Rotation: 0° to 355°

Lens

Lens Type

Fixed

Mount Type

M12

Focal Length

2.5 mm

Max. Aperture

F2.0

Field of View

Horizontal: 135°
Vertical: 90°

Iris Type

Fixed aperture

Close Focus Distance

0.4 m (1.3 ft)

DORI Distance

Detect

Observe

Recognize

Identify

34.5 m

(113.2 ft)

13.8 m

(45.3 ft)

6.9 m

(22.6 ft)

3.4 m

(11.2 ft)

Smart event

General IVS Analytics

Abandoned object; moving object

Heat Map

Yes

Professional, intelligent

Perimeter Protection

Tripwire; intrusion; loitering detection; people gathering.

People Counting

Entry number and exit number counting: Support configuring 4 rules, and display and output Entry number and exit number counting: Support configuring 4 rules, and display and output daily/monthly/annual report
People counting in area: Support configuring 4 rules
Queue management: Support configuring 4 rules, and count the number of people and strand time, and link alarm

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG

Smart Codec

H.264: Yes
H.265: Yes

Video Frame Rate

50 Hz:
Main Stream: 2688 × 1520 @25 fps; sub stream: 704 × 576 @25 fps; third stream: 704 × 576 @25 fps
Main Stream: 2688 × 1520 @25 fps; sub stream: 704 × 576 @25 fps; third stream: 1920 × 1080 @11 fps
60 Hz:
Main Stream: 2688 × 1520 @30 fps; sub stream: 704 × 480 @30 fps; third stream: 704 × 480 @12 fps
Main Stream: 2688 × 1520 @30 fps; sub stream: 704 × 480 @30 fps; third stream: 1920 × 1080 @1 fps

Stream Capability

3 streams

Resolution

2688 × 1520; 2560 × 1440; 2304 × 1296; 2016 × 1512; 1080p (1920 × 1080); UXGA(1600 × 1200); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF(352 × 288/352 × 240)

Bit Rate Control

CBR; VBR

Video Bit Rate

H.264: 32 Kbps–8192 Kbps

H.265: 19 Kbps–8192 Kbps

Day/Night

ICR switch

BLC

Yes

WDR

140 dB

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Manual/Auto

Noise Reduction

3D DNR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest(RoI)

Yes (4 areas)

Electronic Image Stabilization(EIS)

Yes

Smart IR

Yes (Adjust by user)

Defog

Yes

Image Rotation

0°/90°/180°/270°

Mirror

Yes

Privacy Masking

4 areas

Audio

Built-in MIC

Yes

Audio Compression

G.711a; G.711Mu; G726; AAC

Network

Network

RJ-45 (10/100 Base-T)

Protocol

HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; QoS; UPnP; NTP

Interoperability

ONVIF (Profile S/Profile G); CGI; Milstone; Genetec; P2P

Scene self-adaptation

Yes

User/Host

20 (Total bandwidth: 80 M.)

Edge Storage

FTP; NAS; Micro SD card (support max. 256 G)

Browser

IE: Versions later than IE 8
Google
Firefox
Apple: versions later than Safari 12

Management Software

Smart PSS; DSS; P2P

Mobile Phone

IOS, Android

Certification

Certifications

CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
CE-RED: Radio Equipment Directive 2014/53/EU
FCC: 47 CFR FCC Part 15, Subpart B
FCC ID: FCC PART 15C

Port

RS-485

1 (Baud rate range: 1200 bps–115200 bps)

Audio Input

1 channel (Terminal)

Audio Output

1 channel (Terminal)

Alarm Input

1 channel in: 5mA 3V–5V DC

Alarm Output

1 channel out: 300mA 12V DC

Power

Power Supply

12V DC/PoE

Power Consumption

Basic power consumption: 3W (12V DC); 3.6W (PoE)
Max. power consumption (ICR + IR full intensity): 9.5W (12V DC); 11.5W (PoE)

Environment

Operating Temperature

-30°C to +60°C (-22°F to +140°F)

Operating Humidity

≤95%

Storage Temperature

-30°C to +60°C (-22°F to +140°F)

Ingress Protection

IP67; IK10+50J

Structure

Casing

Metal

Dimensions

209.4 mm × 212.0 mm × 103.1 mm

(8.2" × 8.3" × 4.1") (L × W × H)

Net Weight

1365 g (3.0 lb)

Gross Weight

1465 g (3.2 lb)
