Product Overview
PFS3110-8P-96
8-Port PoE Switch (Unmanaged)
> Two-layer industrial PoE switch
> MAC auto study and aging, MAC address list capacity is 8K
> Support IEEE802.3af, IEEE802.3at standard
> Conform IEEE802.3, IEEE802.3u, IEEE802.3ab/z and IEEE802.3X standards
> Industrial wide temperature design
> MAC auto study and aging, MAC address list capacity is 8K
> Support IEEE802.3af, IEEE802.3at standard
> Conform IEEE802.3, IEEE802.3u, IEEE802.3ab/z and IEEE802.3X standards
> Industrial wide temperature design
|
Technical Specification |
|
|
Model |
DH-PFS3110-8P-96 |
|
Ethernet Port |
1*1000 Base-X 1*10/100/1000 Base-T 8*10/100 Base-T (PoE power supply) |
|
PoE Power Consumption |
Each power ≤30W, Total≤96W |
|
PoE Protocol |
IEEE802.3af, IEEE802.3at |
|
Switching Capacity |
7.6G |
|
Packet Forwarding Rate |
4.17Mpps |
|
Packet Buffer Memory |
1Mb |
|
MAC Table Size |
8K |
|
Flow Control |
Enable by default |
|
Application Humidity |
10%~90% |
|
Power |
DC48~57V |
|
Lightning Protection |
Common Mode 4KV Differential Mode 2KV |
|
Working Temperature |
-30°C~65°C |
|
Weight |
540g |
|
Dimension(W×D×H) |
150mm×100mm×42mm |
|
Accessories |
|
|
Model |
|
|
PFT3950 |
1.25G 850nm,500m,LC, Multi-mode |
|
PFT3960 |
1.25G 1310/1550nm,20km,LC, Single-mode |
|
PFT3970 |
1.25G 1550/1310nm,20km,LC, Single-mode |
